Harmsco Premium 2-3/4 in Pleated Polyester Filter Cartridge | Dosinfection

Harmsco Premium pleated polyester cartridges are the industrial-grade depth filter for Harmsco HIF, BC, HMC and FSSS housings and other housings that take 2-3/4 in cartridges. Polyester-Plus media is engineered for high efficiency and very low pressure drop, with about 6 square feet of media per 9-3/4 in of length. They are cleanable and reusable in most applications at 5 micron and above.

0.35 to 100 micron nominal ratings; end caps are color coded by micron for easy identification
9-3/4, 19-1/2, 29-1/4 and 39 in lengths, and nominal 10, 20, 30 and 40 in lengths; 2-3/4 in outside diameter
Standard cartridges are rated to 140 F; high temperature (HT) cartridges to 200 F with urethane end caps; pH 3 to 11
FDA approved materials, NSF 61 certified (standard grades)
Typical flow is 4 to 6 GPM per 9-3/4 in of length

Sold by the case of 24. Flow rates are guidelines; actual flow depends on micron rating, viscosity and solids content.

0.35 to 100 micron nominal ratings; end caps are color coded by micron for easy identification
9-3/4, 19-1/2, 29-1/4 and 39 in lengths, and nominal 10, 20, 30 and 40 in lengths; 2-3/4 in outside diameter
Standard cartridges are rated to 140 F; high temperature (HT) cartridges to 200 F with urethane end caps; pH 3 to 11
FDA approved materials, NSF 61 certified (standard grades)
Typical flow is 4 to 6 GPM per 9-3/4 in of length

Sold by the case of 24. Flow rates are guidelines; actual flow depends on micron rating, viscosity and solids content.
