Harmsco Hurricane Swing Bolt Filter Housing & Separator | Dosinfection

Harmsco Hurricane swing bolt housings are built to ASME design standards for industrial and municipal flows up to 1,200 GPM (higher with the SBHF model). Each cartridge position holds a 30-3/4 in Hurricane jumbo cartridge; choose 1, 3, 5 or 8 cartridges.

Flanged inlet and outlet, O-ring housing seal, swing-bolt closure, stainless standpipes
XP is rated 150 psi; XXP is rated 235 psi; up to 250 F with high-temperature (HTM) cartridges
304 stainless steel electropolished, or 316L; matte finish on the 5-cartridge and larger sizes
Harmsco recommends running at 70 percent of maximum flow for best performance

Flow shown is the maximum with pleated cartridges. Dimensions, floor space and shipping weight are in the manufacturer's data sheet; the 8-cartridge size is built to order.
